Modern Fan Co. Altus 42" 3 Blade Outdoor Ceiling Fan with Custom Blade and Control Options

Features:

• Die cast aluminum fan body
• Blades constructed of plywood
• Includes (1) 4.5" and (1) 16" downrod
• Suitable for damp location

Dimensions:

• Height: 11-11/16"
• Width: 42"
• Canopy Width: 5-3/8"

Blade Options:

• 42" Blade Span
  • Airflow: 5078.06 CFM at high speed
  • Electricity Use: 62 Watts (excludes lights)
  • Airflow Efficiency: 81.9 Cubic Feet per Minute per Watt

Control Options:

• FC-001 Fan Speed Only Control -For a single AC fan, providing four speeds. Not intended for a fan with light. Note: Not compatible with remote control
• FC-003-LED Handheld Remote RF Control -Designed for independent operation a single AC fan (or AC fan with LED light), providing three speeds (and full range dimming - or “on/off” switching), using only one circuit (two wires). Includes RF handset, battery, canopy receiver and comes with a wall-mountable bracket for handset.
• FC-005-LED Wall/Remote Combo RF Control−2 Wire -Designed for independent operation of a single AC fan (or AC fan with LED light), providing three speeds (and full range dimming - or “on/ off” switching), using only one circuit (two wires). Includes RF handset (with battery), RF wall control (with master power switch), switch plate and canopy receiver.

Motor Specifications:

• Motor Size: 153mm x 18mm
• Speeds: 3 or4 (depending on control option)
• Motor: AC Induction

Suggested Downrod Lengths:

• 9 Foot Ceiling: 6" - 12"
• 10 Foot Ceiling: 12" - 18"
• 11 Foot Ceiling: 18" - 24"
• 12 Foot Ceiling: 24" - 36"
• 13 Foot Ceiling: 36" - 48"
• 14 Foot Ceiling: 48" - 60"
• 15 Foot Ceiling: 60" - 72"
